GEO5 Suite software for geotechnical and geological engineers

PILER is the authorized GEO5 partner in Canada. We build on 15 years of geotechnical experience to help you select the right solution.

GEO5 FEM program showing displacement contours around an anchored excavation wall, construction stage 4.
  • GEO5 partner since 2021Authorized dealer for Canada, based in Halifax
  • Phone support on weekdaysMonday to Friday, 9 am to 5 pm EST. Call, text or WhatsApp 902-832-2095
  • Help getting startedInstallation, licence setup and your first models
  • Training and modellingHelp that goes beyond the licence

39 programs, one consistent workflow

GEO5 handles geotechnical tasks with ease, from slope stability and shoring walls to footings, piles, settlement and finite element analysis. Visualize geological information with ease.

Personal: one licence per program and one login email.

Slopes and rock

  • Slope Stability Limit equilibrium slope stability with circular and polygonal slip surfaces. $460 / year
    • Circular or polygonal slip surfaces
    • Bishop, Spencer, Morgenstern-Price, Janbu and other methods
    • Verification according to EN 1997-1 or classical approach
    • Mohr-Coulomb and Hoek-Brown material models
  • Slope Stability – Water Flow Seepage analysis for slope stability models. $460 / year
    • Steady state or transient seepage analysis by FEM
    • Unsaturated zone models: log-linear, Van Genuchten and Gardner
    • Boundary conditions including impermeable and permeable lines
    • Drains and preferential flow paths in the model
  • Nailed Slope Design and check of soil-nailed slopes and walls. $350 / year
    • Soil nail walls and slopes with shotcrete or steel mesh cover
    • Design of the concrete cover
    • Checks for overturning, slip and bearing capacity
    • Stability along straight or polygonal slip surfaces
  • Rock Stability Stability of rock slopes on planar, polygonal and wedge failure surfaces. $460 / year
    • Slip along straight or polygonal slip surfaces
    • Slip of a 3D rock wedge
    • Mohr-Coulomb, Hoek-Brown and Barton-Bandis material models
    • Stereographic projection (Markland test) for rock wedges
  • Anti-Slide Pile Design of piles that stabilize slopes and landslides. $460 / year
    • Internal forces and displacement of piles
    • RC and steel cross-section design to various standards
    • Rock bearing capacity check for piles fixed in rock
    • Modulus of subsoil reaction by Schmitt, Ménard or Chadeisson

Excavations and shoring

  • Sheeting Check Analysis of anchored and strutted shoring walls using subgrade reaction. $460 / year
    • Elasto-plastic non-linear analysis of embedded retaining walls
    • Internal anchor stability and anchor bearing capacity
    • Cross-section verification for steel, RC and timber
    • Check of failure by heave and piping
  • Sheeting Design Preliminary design of cantilever and anchored sheeting walls. $350 / year
    • Design of cantilever walls and basic design of anchored walls
    • Pressure redistribution per EAB and LRFD
    • Verification according to EN 1997-1, LRFD or classical approach
    • RC, steel and timber section design to various standards
  • Earth Pressures Active, passive and at-rest earth pressures, including seismic effects. $350 / year
    • Active, passive and at-rest pressures on structures of any shape
    • Coulomb, Müller-Breslau and other earth pressure theories
    • Effective and total stress parameters
    • Earthquake effects per Mononobe-Okabe, Arrango and Chinese standards

Retaining walls

  • Cantilever Wall Design and check of reinforced concrete cantilever walls. $350 / year
    • Verification according to EN 1997-1, LRFD or classical approach
    • Checks for overturning, slip and foundation bearing capacity
    • Concrete cross-section verification to EC 2, BS 8110, IS456, CSN and PN
    • Earthquake effects per Mononobe-Okabe, Arrango and Chinese standards
  • Gravity Wall Check of gravity walls made of concrete or stone. $350 / year
    • Verification according to EN 1997-1, LRFD or classical approach
    • Checks for overturning, slip and foundation bearing capacity
    • Concrete cross-section checks to EC 2, BS 8110, IS456, CSN and PN
    • Stone masonry verification to EC 6 and GB 50030-2011
  • MSE Wall Design of mechanically stabilized earth walls with geosynthetic reinforcement. $460 / year
    • Internal stability for extensible and inextensible reinforcements
    • Global stability on circular slip surfaces by Bishop or Spencer
    • Built-in database of geo-reinforcements from manufacturer catalogues
    • Verification of foundation soil bearing capacity
  • Gabion Check of gabion retaining walls. $350 / year
    • Verification according to EN 1997-1, LRFD or classical approach
    • Checks for overturning, slip and bearing capacity
    • Check of the gabion material (rock)
    • Mesh overhangs supported with anchorage
  • Masonry Wall Check of masonry and block retaining walls. $350 / year
    • Reinforced masonry wall design to EN 1996-1-1 and AS 3700
    • Any masonry block can be defined
    • Concrete cross-section checks to AS 3600 and EC 2
    • Checks for overturning, slip and bearing capacity
  • Redi-Rock Wall Design of walls built from Redi-Rock precast blocks. $120 / year
    • MSE walls with Redi-Rock precast blocks and Mirafi geogrids
    • Analysis of gravity or MSE wall types
    • Modelling of the entire wall
    • Global stability checked in the Slope Stability program
  • Prefab Wall Check of walls built from prefabricated blocks. $350 / year
    • Generation of the entire wall with 3D visualization
    • Complete list of the blocks used
    • Define your own block sizes or choose from manufacturer catalogues
    • Checks for overturning, slip and bearing capacity

Foundations

  • Spread Footing Bearing capacity and settlement of spread footings. $460 / year
    • Vertical and horizontal bearing capacity
    • Settlement and rotation of the footing
    • Longitudinal and shear reinforcement, including punching
    • Verification of footings in tension
  • Spread Footing CPT Spread footing analysis from cone penetration test results. $460 / year
    • Bearing capacity from CPT by Meyerhof, Schmertmann and Skempton
    • Soil classification by Robertson (1986 or 2010)
    • Settlement from CPT by the Schmertmann method
    • Import of CPT tests in TXT, gINT, AGS or NEN formats
  • Pile Vertical and lateral bearing capacity and settlement of single piles. $460 / year
    • Vertical bearing capacity by Tomlinson and NAVFAC DM 7.2
    • Load-settlement curve by Poulos (linear) or Masopust (non-linear)
    • Horizontal bearing capacity by Broms and p-y methods
    • Verification of steel and timber pile cross-sections
  • Pile CPT Pile bearing capacity and settlement from cone penetration tests. $460 / year
    • Bearing capacity from CPT per EN 1997-2 and NEN 6743
    • Bearing capacity from SPT by Décourt-Quaresma and Aoki-Velloso
    • Limit load curve and pile settlement
    • Negative skin friction
  • Pile Group Analysis of pile groups under a pile cap. $460 / year
    • 3D spring method (FEM) and analytical solutions
    • Vertical bearing capacity of the group per FHWA
    • Group efficiency by UFC 3-220-01A, La Barré and Seiler-Keeney
    • Displacements and internal forces along each pile
  • Micropile Design and check of micropiles. $350 / year
    • Verification of the root and shaft of tube or rod micropiles
    • Buckling check by geometric, Salas and Souch theories
    • Root capacity by Lizzi, Littlejohn, Bowles, Bustamante and others
    • Cross-section check adjusted for the design life
  • Beam Beams and strip footings on elastic subsoil. $350 / year
    • Beam on elastic foundation (Winkler-Pasternak)
    • Subsoil constants C1 and C2 from soil deformation parameters
    • Automatic load combinations per EN 1990
    • Point, moment, strip, trapezoidal and deformation loads
  • Slab Foundation slabs on elastic subsoil. $920 / year
    • FEM design of foundation mats and slabs of any shape
    • Winkler-Pasternak subsoil model with C1 and C2 parameters
    • Subsoil or pile support under the slab
    • Reinforcement design for bending and shear
  • Abutment Design and check of bridge abutments. $460 / year
    • Checks for overturning, translation and bearing capacity
    • Concrete cross-section checks to EC 2, BS 8110, IS456, CSN and PN
    • Verification according to EN 1997-1, LRFD or classical approach
    • Earthquake effects per Mononobe-Okabe, Arrango and Chinese standards
  • Shaft Analysis of vertical circular shafts. $460 / year
    • 3D earth pressures on circular shafts (Berezantsev, Cheng and Hu)
    • Loads on flexible, semi-rigid and rigid shafts
    • Shaft design according to Eurocodes
    • Internal forces in walers by the polygonal method

Settlement

  • Settlement Consolidation settlement under surface loads and embankments. $350 / year
    • Settlement by Janbu, Buisman and soft soil theories
    • Consolidation analysis for time-dependent settlement
    • Secondary settlement according to Ladd
    • Reduced influence zone for structural strength or incompressible subsoil
  • Ground Loss Settlement troughs from tunnelling and their effect on buildings. $920 / year
    • Subsidence troughs by the volume loss method or classical theories
    • Trough shape by Gauss or Aversin approximation
    • Sequential excavation and multiple tunnel tubes
    • Assessment of damage to buildings

Finite element (FEM)

  • FEM 2D finite element analysis of stresses, deformations, excavations and slopes. $1,730 / year
    • Material models including Mohr-Coulomb and Hardening Soil
    • Anchors, nails, props and reinforcements
    • Construction stages with any number of surcharges
    • Factor of safety in each construction stage
  • FEM – Tunnel FEM for tunnels, with linings and staged excavation. $1,730 / year
    • Tunnel lining modelled with beam or 2D elements
    • Relaxation factor for 3D behaviour during excavation
    • Soil swelling and lining shrinkage
    • Automatic generation of anchors fixed to the lining
  • FEM – Water Flow Steady and transient seepage in FEM models. $460 / year
    • Steady state or transient seepage analysis
    • Unsaturated zone models: log-linear, Van Genuchten and Gardner
    • Seepage surface and prescribed pore pressure boundary conditions
    • Resulting water table used in the stress analysis
  • FEM – Consolidation Time-dependent consolidation in FEM models. $460 / year
    • Time-dependent settlement under foundations, embankments and surcharges
    • Different horizontal and vertical permeability
    • Constant or time-dependent loading
    • Development of pore pressure and the water table over time
  • FEM – Earthquake Seismic analysis in FEM models. $460 / year
    • Dynamic analysis with your own or generated accelerograms
    • Generated accelerograms compatible with Eurocode 8 spectra
    • Modal analysis with natural frequencies and mode shapes
    • Rayleigh damping, automatic or user-defined

Geology and site data

  • Stratigraphy 3D geological model from boreholes and field tests. $460 / year
    • Results from boreholes, wells and field tests
    • Import of geological maps and site investigation data
    • 2D and 3D subsoil models from soil profiles
    • Export to IFC and LandXML for BIM
  • Stratigraphy – Logs Borehole and field test logs ready for reports. $460 / year
    • Logs for boreholes, wells and penetration tests
    • Database of predefined templates
    • Your own templates and data reports
    • Export to PDF, DWG, DXF and Word
  • Stratigraphy – Cross Sections Geological cross-sections cut from the 3D model. $460 / year
    • Straight or polyline cross sections
    • Faults and lenses
    • Selected field tests and soil profiles shown on the section
    • Export to PDF, DXF and DWG
  • Stratigraphy – Earthworks Cut and fill volumes from the terrain model. $460 / year
    • Earthworks modelled in construction stages
    • Volumes against previous stages or the original ground
    • Excavation volumes including bulking
    • Terrain from points or from defined earthworks
  • Laboratory Processing and evaluation of soil laboratory tests. $460 / year
    • Grain size distribution, Atterberg limits and Proctor tests
    • Oedometer, shear box and triaxial (UU, CU, CD) tests
    • Evaluation according to EN standards
    • Your own formulas and test templates

Survey and drawing

  • Point Cloud Build terrain models from point cloud survey data. $350 / year
    • Import of LAS, LAZ and E57 point clouds
    • Point clouds of up to 100 million points
    • Cropping the point cloud to the construction site
    • Export of resulting points to LAS and TXT
  • Drawing Editor Edit and finish drawings from GEO5 outputs. $120 / year
    • Bring in pictures from any GEO5 program with one click
    • Dimensions, labels, legends, title blocks and logos
    • Import of DWG, DXF, DGN and IFC drawings
    • Drawings at standard technical scales

Need several programs or more than one licence? Request a quote

Packages

Bundle and save.

Basic Package

A broad set of everyday programs.

$6,900 / year Save 48% Get a quote
What's included (32 programs)
  • Cantilever Wall
  • Gravity Wall
  • MSE Wall
  • Gabion
  • Masonry Wall
  • Redi-Rock Wall
  • Prefab Wall
  • Slope Stability
  • Slope Stability – Water Flow
  • Nailed Slope
  • Rock Stability
  • Anti-Slide Pile
  • Sheeting Check
  • Sheeting Design
  • Earth Pressures
  • Spread Footing
  • Spread Footing CPT
  • Pile
  • Pile CPT
  • Pile Group
  • Micropile
  • Beam
  • Slab
  • Abutment
  • Settlement
  • Stratigraphy
  • Stratigraphy – Logs
  • Stratigraphy – Cross Sections
  • Stratigraphy – Earthworks
  • Laboratory
  • Point Cloud
  • Drawing Editor

Foundation Package

Programs for footings and piles.

$2,500 / year Save 38% Get a quote
What's included (9 programs)
  • Spread Footing
  • Spread Footing CPT
  • Pile
  • Pile CPT
  • Pile Group
  • Micropile
  • Beam
  • Slab
  • Drawing Editor

Excavation Package

Programs for shoring and excavations.

$1,600 / year Save 27% Get a quote
What's included (6 programs)
  • Slope Stability
  • Anti-Slide Pile
  • Sheeting Check
  • Sheeting Design
  • Earth Pressures
  • Drawing Editor

Retaining Wall Package

Programs for retaining wall design.

$1,700 / year Save 42% Get a quote
What's included (9 programs)
  • Cantilever Wall
  • Gravity Wall
  • Gabion
  • Masonry Wall
  • Redi-Rock Wall
  • Prefab Wall
  • Slope Stability
  • Spread Footing
  • Drawing Editor

Geology Package

Programs for site data and geological models.

$1,800 / year Save 35% Get a quote
What's included (7 programs)
  • Stratigraphy
  • Stratigraphy – Logs
  • Stratigraphy – Cross Sections
  • Stratigraphy – Earthworks
  • Laboratory
  • Point Cloud
  • Drawing Editor
Licensing details

Cloud licences

Licences are stored in the cloud and checked when the program starts, which needs an internet connection. For offline work, move a licence to a PC or to an optional hardware key ($80 USD).

Licence types

Prices shown are for one licence. Personal: one licence per program and one login email. Business: up to 5 licences per program and up to 10 login emails. Enterprise: any number of licences and login emails, valid for branches in several countries. Ask us about pricing for more than one licence.

Perpetual licence

Perpetual prices are available.

Students

Enrolled engineering students can get a free 12-month student licence for non-commercial use.

Two ways to buy

Programs start at $120 USD a year. Talk to us for a tailored quote, or order straight from the online shop.

Get a quote

  • A quote built for your team and programs
  • Pay in Canadian or US dollars
  • Discounts available

Buy online

  • Secure checkout
  • Licence delivered by email
  • Cloud activation, no dongle needed

Try GEO5 free

Test every program before you buy, or learn GEO5 while you study.

Free 7-day trial

Full access to every GEO5 program for 7 days, with no credit card.

Call or text 902-832-2095 during your trial for a free walkthrough.

Student licence

Enrolled engineering students can use GEO5 free for 12 months for non-commercial work.

Why buy through PILER

Buying from the authorized GEO5 partner in Canada gets you more than a licence.

Sales and support

We sell and support every program in the GEO5 suite. When you get stuck, call Monday to Friday, 9 am to 5 pm EST, and talk to someone who knows the software.

Training

Get new engineers productive quickly, or refresh your own skills. Sessions are built around the analyses your team actually runs.

Project modelling

Need a hand setting up a tricky model or checking your approach? Ask us about modelling help on your project.

Based in Halifax, working across Canada

PILER has been the authorized dealer of GEO5 products in Canada since 2021, based in Halifax, Nova Scotia. We work with consultants, contractors and universities who need dependable geotechnical analysis software.

About GEO5

GEO5 is developed by Fine, a software company that has been building geotechnical tools since 1989 and is used by engineers in more than 100 countries.

Common questions

Which design standards does GEO5 support?

GEO5 supports LRFD, WSD, and Eurocode 7 with national annexes, with both factor of safety (ASD) and limit states (LSD) design. Standards and partial factors are kept separate from the model, so you can save your own analysis settings and switch between them.

How does the free trial work?

The trial gives you full access to every program for 7 days, with no credit card. Call or text us during the trial and we'll walk you through it.

How do renewal and cancellation work?

A subscription runs for one year from purchase. If you pay by card you can turn on automatic renewal; otherwise you get an invoice 30 days before it ends. A subscription that isn't renewed simply ends, along with access to the software. Fine offers a full refund within 30 days of purchase.

How do I get support?

Call, text or WhatsApp PILER at 902-832-2095, Monday to Friday, 9 am to 5 pm EST, or chat with us here on the site. We help with installation, licence setup and getting your first models running.
